FLAMEBLAZER®

Meet the MAGICFX FLAMEBLAZER, our state of the art liquid flame machine. Extremely fast and reliable because of its high-quality internal pump, dual ignition and its fully integrated, key-activated enable circuit. Blow 10m (L nozzle), 8m (M nozzle) or 6m flames (S nozzle).

Activated and secured by our SFX SAFETY ARM CONTROLLER. Safety for artists, crew and crowd. Without the SAFETY ARM CONTROLLER it's not possible to operate the FLAMEBLAZER.

SKU:
MFX1401
Article GTIN:
8719323575134
INTERNAL
PUMP.

Plug and play flame head.

DUAL
IGNITION.

Fast, responsive firing.

COMPACT
SIZE.

5L fluid can compartment.

S, M AND L
NOZZLE.

For 6, 8 or 10 meter flames.

INTEGRATED, KEY-ACTIVATED
ENABLE CIRCUIT.



REMOTE SFX SAFETY
ARM CONTROLLER.

Next level safety.

Specifications.

Length 41 cm
Width 30 cm
Height 28.1 cm
Weight 18.7 kg
Voltage 220-250 Vac 50/60 Hz
Power 395 W
Control DMX / Pyro 24 Vdc
Consumables Isopar / Isopropanol (IPA)
Consumption S nozzle: 12 ml/s, M nozzle: 30 ml/s, L nozzle: 50 ml/s
Output S nozzle up to 6 m / M nozzle up to 8 m / L nozzle up to 10 m
Not included Power cable and FX-ARM CONTROLLER not included. 1x L-nozzle is standard included.
Warranty 3 years

DOWNLOADS.

Download the user manual for installation and safety instructions. Or download the product sheet for information about the materials of the product.
FLAMEBLAZER MANUAL

Related

Hardware.

SFX SAFETY ARM CONTROLLER
combiner rack.jpg
SFX SAFETY COMBINER 19" RACK
combiner box.jpg
SFX SAFETY COMBINER BOX
SFX SAFETY BEACON
SFX SAFETY E-STOP COVER
SFX SAFETY E-STOP

Accessories.

Schuko to Neutrik® powerCON TRUE1 cable
SFX1401 MAGICFX FLAMEBLAZER Nozzle S-lr.jpg
FLAMEBLAZER® Nozzle S
SFX1402 MAGICFX FLAMEBLAZER Nozzle M-lr.jpg
FLAMEBLAZER® Nozzle M
SFX1403 MAGICFX FLAMEBLAZER Nozzle L-lr.jpg
FLAMEBLAZER® Nozzle L
SFX1404 - FLAMEBLAZER Nozzle Exchange Tool.jpg
FLAMEBLAZER® Nozzle exchange tool
FLAMEBLAZER® Flightcase (for 2 pcs)
MFX3106-Doughty Half Coupler.jpg
Doughty Half Coupler (100 kg) M10
Flexible DMX Cable 5 pole XLR
MFX0340-MFX0341-MFX0342-MFX0343-MFX0344-MFX0345 Data cable etherCON-LR.jpg
SFX SAFETY ARM Data cable (etherCON)
MFX3223-MAGICFX-SFX SAFETY TERMINATOR.jpg
SFX SAFETY TERMINATOR

Consumables.

MFX3086-ISOPAR L-5L.jpg
Flame Fluid Isopar L 5L
Flame Fluid IPA 5L

The FLAMEBLAZER uses isopar or isopropanol (IPA) as fuel, that are projected from a single outlet across spark ignition probes to produce the flame jet. The integrated electric pump draws the fuel from the 5 L can and generates the firing pressure.

With its different types of changeable nozzles (S, M and L), this flame jet can create different flame heights. With the exchange tool, you can differentiate between 6, 8, and 10 meters! It’s equipped with dual ignition, and the flame machine is capable of extremely fast and responsive firing.

The MAGICFX FLAMEBLAZER uses two types of fuel (isopropanol and isopar) to create the flame effect. It has an internal pump and the 5 L flame fluid can is located in the fluid compartment of the machine.

Designed for absolute safety, this FLAMEBLAZER must be controlled by our remote SFX SAFETY ARM CONTROLLER. This way, every FX operator will be able to safely fire this mind-blowing flame machine.

Safely place the FLAMEBLAZER on a solid and even surface or mount it in a truss.

Transport is made easy using our specially designed flight case.

Operate the MAGICFX® FLAMEBLAZER safely! Do not use if there are people, animals or objects in the direct output.
